Background

I was looking into grounded-segment-anything and wanted to use it to segment the objects for my VLA mechanical arm image datasets. Therefore I was looking into the installation of MMCV / Grounding DINO installation to further train it to adapt to my special tasks since the semantical module has no idea what “mechanical arm” is.

However, installing grounding dino is really a pain in the ass. Although I have searched into the internet, it is still rare to see the solutions, but luckily I found one github issue that perfectly solved it. Plus, using grounded SAM project requires 11.3 CUDA, which also potentially causes some troubles.

CUDA 11.3 and installations of torch, torchvision

I honestly have installed at least 30 different environments in last 2 months during my internship in Shanghai Jiaotong University. I have never seen such an environment that asks for CUDA 11.3.

Since 11.3.0 is sometimes buggy for mamba installation if you are a China mainland user. So use 11.3.1 in the following. You can replace mamba with conda if you want to.

mamba install -c "nvidia/label/cuda-11.3.1" cuda-toolkit

Then install corresponding torch and torchvision by pip:

pip install torch==1.12.1+cu113 torchvision==0.13.1+cu113 --extra-index-url https://download.pytorch.org/whl/cu113

Verify the installation by:

nvcc --version
python -c "import torch; print(torch.__version__)"
python -c "import torchvision; print(torchvision.__version__)"

If everything shows CUDA 11.3 and the version of torch and torchvision are correct, you are good to go.

GCC <= 10.0 issue. Versions of your gcc should be between 8.0 to 10.0.

This is also tricky sometimes since your GCC default version in conda might be higher than 10.0. You can check your gcc version by gcc --version.

You can solve this problem by the following commands:

conda install -c conda-forge gcc_linux-64=9.5.0 gxx_linux-64=9.5.0 gfortran_linux-64=9.5.0 -y

If they cannot detect your gcc version, you can try to add the following environment variables:

export CUDA_HOME=$CONDA_PREFIX
export PATH=$CONDA_PREFIX/bin:$PATH
export LD_LIBRARY_PATH=$CONDA_PREFIX/lib64:$CONDA_PREFIX/lib:$LD_LIBRARY_PATH
export CC=$CONDA_PREFIX/bin/x86_64-conda-linux-gnu-gcc
export CXX=$CONDA_PREFIX/bin/x86_64-conda-linux-gnu-g++
export FC=$CONDA_PREFIX/bin/x86_64-conda-linux-gnu-gfortran

⚠️ Attention
I added whatever it possibly stonewalls my installation of Grounding DINO. So be cautious if you dont want to pollute your .bashrc. Use it for one-time thing.

Scalar_type issue in value.scalar_type()

This triggers when you try to compile your Grounding DINO library in python. And also this is the most difficult part to be looked up on the internet. To fix this, according to the github issue in GroundedSAM(or somewhere else, there are many github repos referring to this GroundingDINO project), you should edit the file in models/GroundingDINO/csrc/MsDeformAttn/ms_deform_attn.cu. I will basically give all the code here so all you need to do is replace the code with the following:

		/*!
	**************************************************************************************************
	* Deformable DETR
	* Copyright (c) 2020 SenseTime. All Rights Reserved.
	* Licensed under the Apache License, Version 2.0 [see LICENSE for details]
	**************************************************************************************************
	* Modified from https://github.com/chengdazhi/Deformable-Convolution-V2-PyTorch/tree/pytorch_1.0.0
	**************************************************************************************************
	*/

	#include <vector>
	#include "ms_deform_im2col_cuda.cuh"

	#include <ATen/ATen.h>
	#include <ATen/cuda/CUDAContext.h>
	#include <cuda.h>
	#include <cuda_runtime.h>

	namespace groundingdino {

	at::Tensor ms_deform_attn_cuda_forward(
		const at::Tensor &value,
		const at::Tensor &spatial_shapes,
		const at::Tensor &level_start_index,
		const at::Tensor &sampling_loc,
		const at::Tensor &attn_weight,
		const int im2col_step)
	{
		AT_ASSERTM(value.is_contiguous(), "value tensor has to be contiguous");
		AT_ASSERTM(spatial_shapes.is_contiguous(), "spatial_shapes tensor has to be contiguous");
		AT_ASSERTM(level_start_index.is_contiguous(), "level_start_index tensor has to be contiguous");
		AT_ASSERTM(sampling_loc.is_contiguous(), "sampling_loc tensor has to be contiguous");
		AT_ASSERTM(attn_weight.is_contiguous(), "attn_weight tensor has to be contiguous");

		AT_ASSERTM(value.is_cuda(), "value must be a CUDA tensor");
		AT_ASSERTM(spatial_shapes.type().is_cuda(), "spatial_shapes must be a CUDA tensor");
		AT_ASSERTM(level_start_index.type().is_cuda(), "level_start_index must be a CUDA tensor");
		AT_ASSERTM(sampling_loc.type().is_cuda(), "sampling_loc must be a CUDA tensor");
		AT_ASSERTM(attn_weight.type().is_cuda(), "attn_weight must be a CUDA tensor");

		const int batch = value.size(0);
		const int spatial_size = value.size(1);
		const int num_heads = value.size(2);
		const int channels = value.size(3);

		const int num_levels = spatial_shapes.size(0);

		const int num_query = sampling_loc.size(1);
		const int num_point = sampling_loc.size(4);

		const int im2col_step_ = std::min(batch, im2col_step);

		AT_ASSERTM(batch % im2col_step_ == 0, "batch(%d) must divide im2col_step(%d)", batch, im2col_step_);

		auto output = at::zeros({batch, num_query, num_heads, channels}, value.options());

		const int batch_n = im2col_step_;
		auto output_n = output.view({batch/im2col_step_, batch_n, num_query, num_heads, channels});
		auto per_value_size = spatial_size * num_heads * channels;
		auto per_sample_loc_size = num_query * num_heads * num_levels * num_point * 2;
		auto per_attn_weight_size = num_query * num_heads * num_levels * num_point;
		for (int n = 0; n < batch/im2col_step_; ++n)
		{
			auto columns = output_n.select(0, n);
			AT_DISPATCH_FLOATING_TYPES(value.scalar_type(), "ms_deform_attn_forward_cuda", ([&] {
				ms_deformable_im2col_cuda(at::cuda::getCurrentCUDAStream(),
					value.data<scalar_t>() + n * im2col_step_ * per_value_size,
					spatial_shapes.data<int64_t>(),
					level_start_index.data<int64_t>(),
					sampling_loc.data<scalar_t>() + n * im2col_step_ * per_sample_loc_size,
					attn_weight.data<scalar_t>() + n * im2col_step_ * per_attn_weight_size,
					batch_n, spatial_size, num_heads, channels, num_levels, num_query, num_point,
					columns.data<scalar_t>());

			}));
		}

		output = output.view({batch, num_query, num_heads*channels});

		return output;
	}


	std::vector<at::Tensor> ms_deform_attn_cuda_backward(
		const at::Tensor &value,
		const at::Tensor &spatial_shapes,
		const at::Tensor &level_start_index,
		const at::Tensor &sampling_loc,
		const at::Tensor &attn_weight,
		const at::Tensor &grad_output,
		const int im2col_step)
	{

		AT_ASSERTM(value.is_contiguous(), "value tensor has to be contiguous");
		AT_ASSERTM(spatial_shapes.is_contiguous(), "spatial_shapes tensor has to be contiguous");
		AT_ASSERTM(level_start_index.is_contiguous(), "level_start_index tensor has to be contiguous");
		AT_ASSERTM(sampling_loc.is_contiguous(), "sampling_loc tensor has to be contiguous");
		AT_ASSERTM(attn_weight.is_contiguous(), "attn_weight tensor has to be contiguous");
		AT_ASSERTM(grad_output.is_contiguous(), "grad_output tensor has to be contiguous");

		AT_ASSERTM(value.is_cuda(), "value must be a CUDA tensor");
		AT_ASSERTM(spatial_shapes.type().is_cuda(), "spatial_shapes must be a CUDA tensor");
		AT_ASSERTM(level_start_index.type().is_cuda(), "level_start_index must be a CUDA tensor");
		AT_ASSERTM(sampling_loc.type().is_cuda(), "sampling_loc must be a CUDA tensor");
		AT_ASSERTM(attn_weight.type().is_cuda(), "attn_weight must be a CUDA tensor");
		AT_ASSERTM(grad_output.type().is_cuda(), "grad_output must be a CUDA tensor");

		const int batch = value.size(0);
		const int spatial_size = value.size(1);
		const int num_heads = value.size(2);
		const int channels = value.size(3);

		const int num_levels = spatial_shapes.size(0);

		const int num_query = sampling_loc.size(1);
		const int num_point = sampling_loc.size(4);

		const int im2col_step_ = std::min(batch, im2col_step);

		AT_ASSERTM(batch % im2col_step_ == 0, "batch(%d) must divide im2col_step(%d)", batch, im2col_step_);

		auto grad_value = at::zeros_like(value);
		auto grad_sampling_loc = at::zeros_like(sampling_loc);
		auto grad_attn_weight = at::zeros_like(attn_weight);

		const int batch_n = im2col_step_;
		auto per_value_size = spatial_size * num_heads * channels;
		auto per_sample_loc_size = num_query * num_heads * num_levels * num_point * 2;
		auto per_attn_weight_size = num_query * num_heads * num_levels * num_point;
		auto grad_output_n = grad_output.view({batch/im2col_step_, batch_n, num_query, num_heads, channels});

		for (int n = 0; n < batch/im2col_step_; ++n)
		{
			auto grad_output_g = grad_output_n.select(0, n);
			AT_DISPATCH_FLOATING_TYPES(value.scalar_type(), "ms_deform_attn_backward_cuda", ([&] {
				ms_deformable_col2im_cuda(at::cuda::getCurrentCUDAStream(),
										grad_output_g.data<scalar_t>(),
										value.data<scalar_t>() + n * im2col_step_ * per_value_size,
										spatial_shapes.data<int64_t>(),
										level_start_index.data<int64_t>(),
										sampling_loc.data<scalar_t>() + n * im2col_step_ * per_sample_loc_size,
										attn_weight.data<scalar_t>() + n * im2col_step_ * per_attn_weight_size,
										batch_n, spatial_size, num_heads, channels, num_levels, num_query, num_point,
										grad_value.data<scalar_t>() +  n * im2col_step_ * per_value_size,
										grad_sampling_loc.data<scalar_t>() + n * im2col_step_ * per_sample_loc_size,
										grad_attn_weight.data<scalar_t>() + n * im2col_step_ * per_attn_weight_size);

			}));
		}

		return {
			grad_value, grad_sampling_loc, grad_attn_weight
		};
	}

	} // namespace groundingdino
